SKU: 14040R-8 | UPC: 807298007137
Manley Ford 5.4L Modular V-8 H-Beam Connecting Rod Set 2004-2014
Manley H-Beam connecting rods deliver strength for Ford 5.4L Modular V8 engines found in F-150 trucks Expedition SUVs and E-Series vans. These 6.158-inch rods support high-rpm performance and increased horsepower in stock or built motors. Built to match the standards of Manley Sportsmaster and Pro Series rods at a value price.
Key Features
- Forged 4340 Steel: Aircraft-grade alloy provides durability under extreme boost and nitrous applications
- H-Beam Design: Handles up to 800 horsepower while keeping reciprocating weight low at 618 grams per rod
- ARP 2000 Bolts: 3/8-inch high-strength bolts rated for 220000 psi tensile strength ensure secure big-end clamping
- Precision Dimensions: 2.310-inch big-end bore 0.927-inch small-end bore and 2.1228-inch journal for direct fit with OEM crank and pistons
- Lightweight Construction: Reduces rotating mass for quicker revs and better throttle response in 5.4L 3V builds
Product Notes
- Designed for press-fit wrist pins. compatible with most aftermarket 5.4L pistons
- Inspect rod bolts during assembly and replace if worn
- Ships in protective packaging to prevent shipping damage
Installation Notes
- Professional installation recommended.
- Torque ARP bolts to 60 ft-lbs with ARP moly lube using angle-torque method
- Requires resized big ends and honing for optimal piston-to-wall clearance
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2004-2008 | Ford | F-150 | 5.4L V8 |
| 2004-2010 | Ford | Expedition | 5.4L V8 |
| 2006-2014 | Ford | E-150 | 5.4L V8 |
| 2006-2014 | Ford | E-250 | 5.4L V8 |
| 2006-2014 | Ford | E-350 | 5.4L V8 |
| 2005-2007 | Ford | F-250 Super Duty | 5.4L V8 |
| 2007 | Lincoln | Navigator | 5.4L V8 |
| 2007 | Ford | Lincoln Mark LT | 5.4L V8 |
Why Choose Manley?
- Over 60 years in performance engine parts manufacturing
- USA-made with rigorous quality control and dyno testing
- Proven design used in drag racing and street performance builds
Frequently Asked Questions
- Q: Will these rods fit my 2006 F-150 5.4L 3V engine?
A: Yes direct replacement for stock rods in 2004-2008 F-150 5.4L Modular engines with 6.158-inch length - Q: What material are the rods made from?
A: Forged 4340 chromoly steel with 100% ultrasonic testing and magnaflux inspection for crack-free reliability - Q: What is the warranty on these connecting rods?
A: Manley offers a limited lifetime warranty against manufacturing defects when installed by a qualified builder
Shipping & Handling
- Method: UPS Ground
- Availability: In stock – ships same or next business day
- Packaging: Secure foam-lined box 4 x 12 x 28 inches
- Weight: 11.2 lbs
Reviews
There are no reviews yet.
