SKU: 164504 | UPC: 00840103408828
ICON 2017+ Ford Super Duty 4 Link Frame Bracket Kit
Upgrade your Ford Super Duty with the ICON 4 Link Frame Bracket Kit, designed for 2017-2022 F-250 and F-350 models. This kit replaces the factory radius arm setup with a high-performance 4-link system using competition-grade spherical bearings to boost front suspension articulation and precision handling. The design cuts deflection for sharper truck response while delivering an aggressive stance.
Key Features
- Spherical Bearings: Competition-grade bearings replace bushings to reduce deflection and enhance overall handling precision
- Pinch Bolt Housing: Patented design on lower links allows on-truck caster adjustability without disassembly
- Heavy-Duty Construction: Laser-cut 3/8-inch steel plate brackets with CNC bending ensure maximum strength and durability
- Powdercoat Finish: Black powdercoated for corrosion resistance and long-lasting performance in harsh conditions
- Complete Hardware: Includes all Grade 8 bolts, heim joints, and mounting hardware for straightforward integration
Product Notes
- Requires ICON 4-Link Conversion Kit components for full installation
- Designed for 4×4 models only. 2WD not compatible
- Ships fully assembled with protective packaging
Installation Notes
- Professional installation recommended.
- Compatible with ICON tubular control arms and coilover kits
- Requires frame drilling. use provided hardware for secure mounting
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2017-2022 | Ford | F-250 Super Duty | King Ranch |
| 2017-2022 | Ford | F-250 Super Duty | Lariat |
| 2018-2022 | Ford | F-250 Super Duty | Limited |
| 2017-2022 | Ford | F-250 Super Duty | Platinum |
| 2017-2022 | Ford | F-250 Super Duty | XL |
| 2017-2022 | Ford | F-250 Super Duty | XLT |
| 2017-2022 | Ford | F-350 Super Duty | King Ranch |
| 2017-2022 | Ford | F-350 Super Duty | Lariat |
| 2018-2022 | Ford | F-350 Super Duty | Limited |
| 2017-2022 | Ford | F-350 Super Duty | Platinum |
| 2017-2022 | Ford | F-350 Super Duty | XL |
| 2017-2022 | Ford | F-350 Super Duty | XLT |
Why Choose ICON?
- Proven leader in vehicle dynamics for trucks and SUVs
- Billet aluminum and chromoly components built for extreme off-road use
- Precision engineering from in-house manufacturing and testing
Frequently Asked Questions
- Q: Does this fit 2023 Ford Super Duty models?
A: Primary fitment covers 2017-2022 F-250/F-350 4×4. verify with ICON for later years as chassis remains similar - Q: What material are the brackets made from?
A: 3/8-inch laser-cut steel plate with black powdercoat finish for strength and rust protection - Q: What is the warranty on this kit?
A: ICON offers lifetime warranty on frame brackets and Delta Joint components against defects
Shipping & Handling
- Method: Ground shipping via UPS/FedEx
- Availability: In stock – ships same or next business day
- Packaging: Oversized box 24 x 12 x 10 inches
- Weight: 28 lbs
Reviews
There are no reviews yet.
