SKU: K93052
ICON 2010-2014 Ford F-150 SVT Raptor Stage 2 Suspension System
Upgrade your 2010-2014 Ford F-150 SVT Raptor with the ICON Stage 2 Suspension System featuring 2.5 Series front coilover shocks and rear shocks with internal reservoirs plus hydraulic bump stop kit. This complete kit delivers precise damping control through Compression Damping Control Valves (CDCV) and advanced bump stop technology for maximum wheel travel and bottom-out resistance. Engineered for high-speed desert running and technical off-road trails it maintains full suspension articulation under normal driving while ramping up forces at high speeds.
Key Features
- Hydraulic Bump Stops: Use oil and nitrogen for dual spring and shock function with adjustable tuning for low initial impact forces that ramp to high resistance preventing harsh bottoming and kickback.
- 2.5 Inch Travel Air Bump: Allows shocks extra distance to absorb energy without limiting suspension travel during everyday driving conditions.
- Clamshell Bracket Design: Provides rigid mounting with triangulated cross braces to reinforce frame weak points prone to failure under extreme loads.
- 2.5 Series Shocks with CDCV: Front coilovers and rear shocks feature 10 levels of compression damping adjustment vehicle-specific valving and internal reservoirs for consistent fade-free performance.
- Delta Joint Upper Control Arms: Included for extended durability over stock ball joints with greaseable serviceable design.
Product Notes
- Designed as bolt-on installation for direct fitment no cutting or welding required.
- Requires front end alignment after installation for optimal handling.
- Ships as complete kit with all necessary hardware spacers and bump stop components.
Installation Notes
- Professional installation recommended.
- Full kit installs in approximately 8-12 hours with standard tools and lift.
- Compatible with stock or aftermarket wheels and tires includes Delta Joint hardware.
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2010-2014 | Ford | F-150 | SVT Raptor |
Why Choose ICON?
- Proven in Baja 1000 racing with real-world off-road validation.
- USA-made components with corrosion-resistant finishes for long-term durability.
- Precision-tuned valving matches Raptor dynamics for balanced ride quality.
Frequently Asked Questions
- Q: Will this fit my 2010-2014 Ford F-150 SVT Raptor exactly?
A: Yes this system is vehicle-specific for all 2010-2014 SVT Raptor models including SuperCab and Crew Cab configurations with no modifications needed. - Q: What lift height does it provide?
A: Offers 0-3.5 inches of front lift height adjustable via coilover spring perch with matched rear ride height for level stance. - Q: What is the warranty coverage?
A: ICON provides lifetime warranty on coilover shocks against manufacturing defects with 1-year on other components register online for full details.
Shipping & Handling
- Method: UPS Ground or Freight
- Availability: In stock – ships same or next business day
- Packaging: Single oversized box 42 x 20 x 14 inches
- Weight: 92 lbs
Reviews
There are no reviews yet.
