SKU: 14009097010 | UPC: 840232702446
BorgWarner SuperCore Assembly SX-E S400SX-E 80mm 110/96 for 2010-2022 Cummins 6.7L
The BorgWarner SuperCore Assembly SX-E S400SX-E 80mm 110/96 is the center heart of high-performance S400 frame turbochargers. This ball-bearing CHRA fits custom turbo builds on 2010-2022 Dodge Ram Cummins 6.7L Ford Powerstroke 6.7L and GM Duramax 6.6L trucks. It supports 1000-1200 HP with rapid spool-up and massive airflow for street and track dominance.
Key Features
- 80mm Billet Compressor Wheel: 80.35mm inducer 110.5mm exducer 60 trim design flows 110+ lbs/min for dyno-crushing boost
- 96mm Inconel Turbine Wheel: 99.65mm inducer 96.55mm exducer 88 trim withstands 1600+ degrees F for reliability under extreme power
- Dual Ceramic Ball Bearing Cartridge: Cuts friction by 60% enables 15000 RPM/s acceleration for instant throttle response
- Investment Cast Center Housing: Oil-cooled journal backup with water ports prevents coking in long-haul diesel duty
- Pre-Balanced Assembly: Factory VSR balanced to 120000 RPM supports drop-in core swaps with zero vibration
Product Notes
- Super core only compressor turbine housings oil lines sold separately
- Inspect bearings during assembly use high-quality assembly lube
- Ships ready for 9cm2 10cm2 or 12cm2 housings standard UPS ground
Installation Notes
- Professional installation recommended.
- Match with S400SX-E compressor A/R .88 turbine A/R 1.00-1.32 housings
- Requires -4AN oil feed -10AN drain lines T4 flange compatible
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2010-2022 | Dodge/Ram | 2500/3500 | 6.7L Cummins |
| 2011-2022 | Ford | F-250/F-350/F-450 Super Duty | 6.7L Powerstroke |
| 2006-2019 | Chevrolet/GMC | 2500HD/3500HD | 6.6L Duramax |
| 2007.5-2022 | Dodge/Ram | 3500/4500/5500 | 6.7L Cummins Chassis Cab |
Why Choose BorgWarner?
- Direct OEM supplier to Cummins Ford GM for proven diesel reliability
- Endurance-tested in NHRA Pro Stock and NASCAR for zero failures
- Precision CNC machined in USA with aerospace tolerances
Frequently Asked Questions
- Q: Does this super core bolt directly into stock turbo housings?
A: Designed for S400SX-E frame housings common on aftermarket kits for Cummins 6.7L verify flange match - Q: What is the turbine wheel material?
A: Inconel 713C withstands extreme EGTs ideal for tuned diesels over 1000 HP - Q: What warranty applies?
A: 1-year unlimited mileage when installed by certified shop covers defects in materials workmanship
Shipping & Handling
- Method: UPS Ground
- Availability: In stock – ships same or next business day
- Packaging: Protective foam-lined box 16 x 16 x 16 inches
- Weight: 28 lbs
