SKU: 703013 | UPC: 819314020877
Baja Designs S8 Series Driving Combo Pattern 30in LED Light Bar – Amber
Baja Designs S8 30-inch straight LED light bar in Driving Combo pattern with Baja Amber lens combines long-range spot and wide flood beams for superior off-road illumination. Universal design mounts on trucks Jeeps SUVs UTVs with included brackets. Outputs 19050 raw lumens of 5000K daylight at 180 watts to cut through dust fog rain reducing driver fatigue.
Key Features
- High Output: 19050 raw lumens from 24 Cree LEDs eight per 10-inch section powered by CopperDrive technology for 100 percent drive without excess heat
- Beam Pattern: Driving Combo projects forward light where needed ClearView optics focus every lumen precisely with amber backlight for vehicle matching
- Durability: IP69K waterproof submersible exceeds MIL-STD810G MoistureBlock seals against pressure washing IK10 impact resistant aircraft-grade aluminum hard anodized housing
- Dimensions: 30 inches long 1.6 inches high 3 inches deep weighs 6.5 pounds billet machined aluminum bezel hardcoated polycarbonate lens black housing
- Performance Specs: 12 amps 49930 hour life overvoltage protection 5000K color stainless steel mounting hardware included uService replaceable lenses optics
Product Notes
- Wiring harness not included order 640122 On/Off with mode switch for backlight or 640115 On/Off 3-pin for 10-30 inch lights
- Add-ons include rock guard 708201 amber light cover 708202 clear light cover 708203 lens kits 708313 708314 anti-theft kits 660302 660303 harness splitters 613608 640163
- Lighting modes beam and amber backlit forward projecting universal fit
Installation Notes
- Professional installation recommended.
- Mounts with included stainless steel brackets hardware
- Separate harness required compatible with upfitter 640094 backlit add-on 640177 hi-beam splitter 640163
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| 1987-2024 | Jeep | Wrangler | JK JL TJ YJ All |
| 2005-2024 | Toyota | Tacoma | All |
| 2019-2024 | Ford | Ranger | All |
| 2004-2024 | Chevrolet | Colorado | All |
| Universal | All | Trucks SUVs UTVs | – |
Why Choose Baja Designs?
- LED pioneers with motorsports heritage patent D780964
- Aircraft-grade materials Mil-Spec testing for extreme conditions
- Replaceable components uService for long-term reliability
Frequently Asked Questions
- Q: Does this light bar fit my Jeep Wrangler or Toyota Tacoma?
A: Yes universal mounting brackets included fits 1987-2024 Jeep Wrangler all models 2005-2024 Toyota Tacoma plus most off-road trucks SUVs UTVs - Q: What materials are used in construction?
A: Aircraft-grade aluminum housing with Mil-Spec hard anodize billet aluminum bezel hardcoated polycarbonate lens stainless steel hardware - Q: What warranty and harness details apply?
A: Limited Lifetime Warranty plus 30-day satisfaction guarantee harness not included use 640122 for backlight mode or 640115 for basic on/off
Shipping & Handling
- Method: Standard Ground
- Availability: In stock – ships same or next business day
- Packaging: Secure box protects 30x3x4 inch light bar during transit
- Weight: 6.5 lbs
Reviews
There are no reviews yet.
